廠家直銷電子密碼鎖 爆款更衣柜密碼柜鎖 鋅合金文件柜密碼鎖

密碼鎖詳細說明  coded lock Detailed instructions

一.功能特點（Features）:

1. 聲音提示功能（voice prompts）：

 操作電子柜鎖時有不同的聲音提示

 When operating the electronic cabinet lock has a different voice prompts

2. 燈光提示功能（light prompts）：

 三種顏色的燈光提示(黃色燈代表報警,紅色燈代表低壓,綠色燈代表開鎖)

 Tip three colors of light (yellow light on behalf of the police, on behalf of low red
 light, green light on behalf of unlocking)

3. 應急開門功能（emergency door features）：

1)在內部沒電或電池電壓不足驅動電機的情況下，可用外接電源供電開鎖；
   in-house without electricity or battery-voltage-driven motor in the case, can unlock
   the external power supply;

2)當用戶遺忘密碼時，可使用管理密碼或跳碼開鎖；
   When the user forgets the password, you can use the admin password or unlock code hopping;

4. 低壓報警功能（low-voltage alarm function）：

 在電壓過低時，輸入密碼開鎖后紅燈閃爍并伴有四組群聲報警，在低壓報警后

 可開鎖100次左右. 建議您盡快更換電池。

 When the voltage is too low, enter the password lock and accompanied by four flashing
 red light after the groups sound the alarm, the alarm can lock in low pressure about 100
 times. We recommend that you replace the batteries as soon as possible.

5. 密碼位數（digit password）:


 用戶密碼和管理密碼為4-10位，軟件跳碼固定為10位數
 User and admin password of 4-10 bits, software-digit jump code is fixed at 10

6.密碼恢復（Password Recovery）:


1）當用戶遺忘密碼時,使用管理密碼即可完成開鎖同時將用戶密碼恢復為出廠密碼；
     When the user forgets the password, use the admin password to unlock the same time to
     complete the user password to the factory password;

2）當管理密碼遺忘時，長按主板上的復位開關三秒即可將管理密碼恢復為出廠管理碼。

     When the administration password is forgotten, long press on the motherboard reset
     switch three seconds to the management password to the factory management code.

7. 多級密碼管理（Multi-level password management）：


 用戶密碼、管理密碼和跳碼分級管理,用戶密碼和管理密碼都可以根據客戶需求自行修改.

 User password, manage passwords and code hopping hierarchical management,

 user and admin password can modify according to customer needs.

8.密碼保護功能（Password protection）:


 當密碼輸入錯誤，黃燈閃爍四次同時蜂鳴四聲，如果連續輸入三次錯誤密碼，

 柜鎖主板被鎖定5分鐘,此時操作按鍵無反應，可有效的防止惡意竊取密碼.

 When the password input error, the yellow light flashing four beep tones at the same

 time, if the continuous input the wrong password three times, the motherboard is locked
 cabinet lock 5 Minutes, and the operation buttons no response, can effectively prevent
 malicious theft of passwords.

9. 模式切換功能（Mode switching function


 獨立式與開放式可通過管理密碼進行切換。

 Stand-alone with an open switch can manage the password.

10. 狀態提示功能（state prompts ）


 在開放式模式下，可以設置在關鎖狀態下經燈閃爍，提示柜鎖己被使用

（證明此柜鎖己經有人占用，此功能公適用于開放放模 式，應用于公共場所）

 In open mode, the lock can be set in the off state by light flashes, indicating cabinet
 locks have been used (to prove this cabinet locks have been Occupation, this feature

 applies to open up the public mode, used in public places)

11. 亂碼功能 （可選擇戶用亂碼功能，產品出廠前未啟動）


 開鎖密碼可隨意輸入，只要連續輸入（比如正確密碼是1234，你可以 輸入36582141234

 或123435984236，也可以36235123435962都可以開鎖）包含有正確密碼就可以開鎖，

 有效防止他人旁觀竊取密碼。
 從開始輸入正確密碼到結束（含隨機亂碼），不可超過20位，否則系統提示錯誤。

 Unlock password can be free to enter, as long as continuous input (such as the correct

 password is 1234, you can enter 36582141234 or 123435984236, you can 36,235,123,435,962
 can unlock) contains the correct password can unlock, prevent others On the sidelines to
 steal passwords. Enter the correct password from the beginning to the end (with random
 garbage), not more than 20, otherwise the system prompts an error.

12. 可選功能（Optional features）


 使用PDA數據采集器可以查看最近開鎖的（200條開以內）記錄，（包括開鎖時間、

 開鎖密碼,身份），采集數據完畢后，可以在軟件上或手持機上讀

 Data acquisition using a PDA can view recently unlocked (open less than 200) records

 (including time lock, unlock password, identity), After collecting data, software or can

 be read on handheld devices

 工作溫度:-25℃ ~ +60℃

 Operating Temperature: -25 ℃ ~ +60 ℃

 工作濕度:5%RH~ 95%RH
 Operating Humidity: 5% RH ~ 95% RH

 靜態電流：指示燈熄滅時靜態電流:≤5uA

 Quiescent Current: indicator is off quiescent current: ≤ 5uA

 啟動時瞬間（開鎖時）電流：≤250mA

 instant start (Unlock) Current: ≤ 250mA

 操作按鍵的工作電流：≤20mA
 operation key operating current: ≤ 20mA

 電池壽命:正常情況下,開門﹥20000次，12個月以上,欠壓報警后仍可開門100次左右

 Battery Life: Under normal circumstances, open the door> 20,000 times, more than 12
 months, under-voltage alarm can open the door about 100 times

 抗靜電:空氣放電15KV，接觸放電8KV

 static: Air Discharge 15KV, contact discharge 8KV

 工作電源：四節七號優質堿性電池

 Power Supply: Four AAA alkaline batteries quality

 電池電源通斷電,電路不受偶然斷電影響，再次通電時系統不會死機或出現異常情況

 battery power through the power circuit from accidental outages, the system will not
 crash again, power or unusual circumstances

廣泛適用于游泳浴場、桑拿浴場、高爾夫球場、健身房的更衣柜，
機關、企業、學校、酒店賓館、超市的文件柜或儲物柜等.
